- Description
- Features
- Download
-
Features:
1. Optimize the imaging effect within the working range of 600mm color selection standard.
2. M42*1 threaded interface, with the adapter interface can be matched with all kinds of interfaces.
型號
Model
F50DMB28
F50DMB40
F50DMB28
F50DMB40
焦距
Focal Length
50mm
50mm
50mm
50mm
標準放大倍率
Standad Magnificaition
0.0946
0.094
0.0946
0.094
像面尺寸
Image Size
φ30
φ30
φ30
φ30
光圈
Iris(F)
F2.8
F4
F2.8
F4
光學畸變
Optical Distortion
-0.61%
-0.61%
-0.61%
-0.61%
相對照度(%)
Relative Illuminace
95.5%
95.5%
95.5%
95.5%
工作距離
Working Distance
574
574
574
574
最優工作距離
Optimal Working Distance
600mm-700mm
600mm-700mm
600mm-700mm
600mm-700mm
接口
Mount
M42*1
M42*1
M42*1
M42*1
法蘭距
Flange Length
12
12
5.9
5.9
分辨率
Resolution
5.5K 5μ
5.5K 5μ
5.5K 5μ
5.5K 5μ
-
-
